    Farm Irrigation extinguish a fire Forest fire fighting Drainage FUMAI 3 inch aluminum alloy Horizontal clean water pump

    Ask Lasest Price
    Brand Name : FUMAI
    Model Number : fmwp800
    Certification : CE
    Price : Negotiate
    Payment Terms : T/T
    Supply Ability : 20000
    Delivery Time : 10
    • Product Details
    • Company Profile

    Farm Irrigation extinguish a fire Forest fire fighting Drainage FUMAI 3 inch aluminum alloy Horizontal clean water pump

    Water pump maintenance instructions


    the running-in period is about 5-10 hours, you have to change the oil, otherwise the impurities in the oil tank in the running-in period will jam the crankshaft .
    Fill the four-stroke gasoline engine with gasoline above 90# and add lubricating oil to the tank. Please check the oil level before each use.
    When the gasoline engine is working continuously, the crankcase temperature should not exceed 90 degrees. When it is overheated, it should be shut down for 15-20 minutes and then continue to work. When adding gasoline, it must be cooled down.
    It is forbidden for gasoline engines to stop at high speeds, and the throttle should be lowered to the lowest speed before stopping.
    Use the correct type of engine oil, clean engine lubricating oil without impurities, and gasoline without impurities.
    The air filter element should be checked regularly and replaced regularly. The dirty filter element should be washed with soapy water and dried before use.
    The machine is like your car, and it needs frequent care and maintenance to extend its life.




    Fmai open impeller single suction aluminum alloy horizontal vortex pump clean water pump
    Water pump
    Specifications
    Model FMWP800
    engine parameter
    Engine model 168FB
    Engine typeOHV25 single cylinder,Forced air cooling,4-stroke
    EnginePower kW/RPM3.5/3600
    Ignition systeminduction ignition
    Starting systemrecoil start
    Fuel tank capacity3.6L
    Oil capacity0.6L
    Water pump parameter:
    Intel Dia80mm(2inch)
    Output Dia80mm(2inch)
    Lift head15.8m
    Max.suction head5m
    Max.flow rate39.6m3 /h
    M.T mm520*395*420
    Self-priming time (s)≤150
    Cavitation allowance (m)4.0
    Net weight (kg)25±1
    G.W KG26
    MaterialAluminum Alloy Aluminum Alloy
    Drive modemanual
    UseIrrigation,extinguish a fire,Drainage
    Pump shaft positionhorizontal
    Impeller structureOpen impeller
    Number of impellersSingle stage
    Impeller suction methodSingle suction
    Principlevortex pump
    Performancenon-blocking
    Conveying mediumclean water pump

    The gasoline engine water pump is a centrifugal pump composed of a water pump and a bracket. It has the advantages of low cost, light weight, convenient maintenance, and low manufacturing cost and low noise.
    Uses: flood control and drainage, fire fighting, farmland irrigation, mountain water delivery, garden irrigation, etc.
    1. The water pump has the advantages of simple installation, small footprint, convenient maintenance, and no noise.
    2. The overall structure is compact, small in size, low in noise, energy-saving and environmentally friendly, and convenient for maintenance. There is no need to build a pump room, and it can work when it is submerged in the water.
    3. The impeller design is advanced, the large flow channel can pass long fibers and dirt, and has strong anti-clogging, anti-winding and flow capacity.
